Newinline Turbine Flow Meter 1
Newinline Turbine Flow Meter 1

Newinline Turbine Flow Meter

Inquiry

A vortex flow meter is a type of flow meter used to measure the flow of fluids, such as liquids, gases, and steam. It works on the principle that when a fluid flows past an obstruction in a pipe, vortices or swirls are created downstream of the obstruction. These vortices cause a pressure fluctuation which is detected by a sensor in the flow meter, and the frequency of these pressure fluctuations is proportional to the fluid flow rate. The vortex flow meter is a reliable and accurate flow meter that is commonly used in a variety of industries, including chemical, oil and gas, and water treatment.

Advantages of vortex flow meter:

Accurate measurement: Vortex flow meters are known for their high accuracy and reliability, making them a popular choice for measuring flow in a wide range of applications.

No moving parts: Unlike some other flow meters, vortex flow meters do not have any moving parts, which means they are less prone to wear and tear and require minimal maintenance.

Wide turndown ratio: Vortex flow meters have a wide turndown ratio, which means they can accurately measure flow over a wide range of flow rates.

Suitable for a wide range of fluids: Vortex flow meters can be used to measure the flow of gases, liquids, and steam, making them versatile and suitable for a wide range of applications.

Minimal pressure loss: Vortex flow meters have a low pressure loss, which means they can accurately measure flow without significantly affecting the pressure of the fluid being measured.

Digital output: Many vortex flow meters offer digital output, which means they can be easily integrated into digital control systems for improved process automation and control.

Vortex flow meter accuracy has the characteristics of high accuracy, good repeatability, convenient installation and maintenance, and simple structure.

Liquid flows through the turbine casing, causing the internal rotor to rotate. When the rotor rotates, an electrical signal is generated in the pickup coil. This signal is converted to engineering units (liters, cubic meters, gallons, etc.) on the applicable local display. Optional accessory modules can be used to export signals to other devices.

Make sure the turbine flow model meets your specific needs. For your future reference, if this information becomes unreadable on the turbine, it may be useful to record it on the nameplate of the manual. See the nameplate for your custom product specifications.

How to choose vortex flow meter?

When it comes to choosing a vortex flow meter, it is essential to understand its operation and the various factors that can have an effect on its functioning. It is therefore necessary to review the application requirements and pick out the right vortex meter for the fluid being measured. These instruments are versatile enough to measure liquids, gases or steam in a vast array of temperatures and pressures. Moreover, evaluating the required levels of accuracy is also important as different models provide differing degrees of precision. Additionally, it's important to bear in mind variables such as line size, pressure drop limitation and desired turndown ratio when aiming for accurate readings.

In addition, it is important to understand the installation conditions when selecting the right vortex flow meter. The placement should be carefully determined to avoid disturbances caused by upstream turbulence or insufficient straight pipe lengths before and after the meter's location. Furthermore, determining whether to use inline or insertion meters depends on factors such as space, maintenance considerations, and budget constraints.

There are many additional features offered by certain manufacturers that are beneficial in terms of technology advancements within this field. Modern vortex flow meters, for example, include advanced diagnostic capabilities such as temperature sensors or signal processing algorithms that enhance measurement stability even under challenging process conditions.

It is also crucial to consider the long-term costs associated with owning a vortex flow meter during the selection process. Before making any decisions, it is important to consider factors such as the purchase price, maintenance costs, and calibration frequency.

Last but not least, ensuring compliance with industry standards ensures compatibility with existing systems while providing reliable data output.Want to know more about vortex flow meter, contact Sincerity Group, a professional vortex flow meter supplier & manufacturer with over 30 years of experiences.

Product Description


Product

Battery power supply- with local display

Signal output

None

Power supply

Battery

Accuracy

±0.5%

Measuring range

Standard range/ expanded range

Display

yes

Medium temperature

-20- 80℃

Environment temperature

-20- 50℃


Newinline Turbine Flow Meter 2

SIXE

Newinline Turbine Flow Meter 3
Newinline Turbine Flow Meter 4

DETAIL DISPLAY

Newinline Turbine Flow Meter 5
1.LASTER MARKING
Each sensor has its own special series number SS304 -perfect for the complicated local environment Long working hours and resistant to rust.
Newinline Turbine Flow Meter 6
2.HIGH RSEISRANCE IMPELLER
Special ordered,advances anti-seize Impeller.With turbine guide parts to ensure the fluid is flowing smoothly. The impeller will not be easily broken .The life time is 4-5 times longer than normal floe meters.
Newinline Turbine Flow Meter 7
3.INTELLIGENT TRANSMITTER
Local displaying unit.Strong anti-jamming ability combination keys easy to operate.
Newinline Turbine Flow Meter 8
4.ONE CLICK TO CLEEAR ZERO
Standard one-click zero clearance button .suitable for non-long-time measurement. Often clear zero laboratories,and other working conditions. Easy to use.
Newinline Turbine Flow Meter 9
5.AVIATION PLUG
Quality stainless steel aviation plug .Quality aviation plug. Strong sealing,stable signal defeat inferior plastic plugs
Newinline Turbine Flow Meter 10
6.EXPLOSION-PROOF ENCLOSURE
Professional explosion-proof shell. Widely used in various operating environments Water-proof ABS electrical interface to extend the life time.Extended service life.

Other Products


Company Advantages

· Sincerity Group inline turbine flow meter is finely finished using the most advanced production equipment in the industry.

· A strict quality guarantee system is established to guarantee the quality of this product.

· The product is warmly welcomed and widely applied by our global customers thanks to its remarkable advantages and high economic benefits.


Company Features

· Beijing Sincerity Automatic Equipment Co., Ltd has a wealth of experience in producing inline turbine flow meter and is committed to providing the highest quality products.

· Beijing Sincerity Automatic Equipment Co., Ltd finishes all the projects with total professionalism.

· We put emphasis on sustainability work. We have a close dialogue with suppliers and business partners about the adoption of sustainable materials.


Application of the Product

Sincerity's inline turbine flow meter is widely used in multiple industries and fields.

Sincerity is rich in industrial experience and is sensitive about customers' needs. We can provide comprehensive and one-stop solutions based on customers' actual situations.

Contact us
we welcome custom designs and ideas and is able to cater to the specific requirements. for more information, please visit the website or contact us directly with questions or inquiries.
