Coriolis Mass Flow Meter - - Sincerity Group
Product details of the coriolis mass flow meter
Product Introduction
The Sincerity Group coriolis mass flow meter is produced using quality raw materials and smart technology. It continuously set and then exceed the standard for what it should be. Perfect after-sales service of Beijing Sincerity Automatic Equipment Co., Ltd is gradually recognized by the majority of customers.
Product Display
THE MOST ACCURATE MEASURING METHOD IN THE WORLD
Screen Comparison
Beijing Sincerity, 32 years of experience, excellence in Coriolis production.
Product advantage
CONNECTIONS:
Connections can be specially customized based on your own requirements. GB Flange/ ANSI/ DIN/ JIS Flanges / threaded connections/ Tri-clamp connections, etc.
OUTPUT:
4-20mA, 0-10KHz, Standard RS 485 communication protocol, HART
Material:
We can customize the materials for you as your requirements, including SS316L, HC Hastelloy, SS 2205 steel, Titanium, etc.
Integrated type/ Separated type
Can be customized as your requirements. For the high temperature measurement with more than 150℃, it is recommended to use the separated type. Standard cable length of 1 meter.
Waterproof & Explosion- proof threading hole. With explosion proof rate of ExdibIICT6Gb.
OEM We support OEM lables. We can customize everything on lables for you, even for the inner software.
Choose your own customized
Coriolis mass flow meters
Application | U-SHAPE | TRIANGLE TYPE | MICRO BEND V-HAPE |
Most common | CNG/ LNG/ LPG dispensers | High viscosity and super | |
Pipeline size | DN1-DN300 | DN10-DN25 | DN10-DN300 |
Minimum flow rate | 0-1kg/h | 0-1500kg/h | 0-1000kg/h |
Parameters of mass flowmeter
Model | Nominal line size | Maximum flow rate | Working Pressure | Connection type | ||
Inch | Mm | lb/min | Kg/h | MPa | Mm | |
DMF-1-1-A | 1/8" | DN 3 | 1.47 | 40 | 0~4 | Weld Joints Φ6×1.5 |
DMF-1-1-B | 1/6" | DN 6 | 3.67 | 100 | 0~4 | Weld Joints Φ10×2 |
DMF-1-2-A | 1/4" | DN 8 | 7.35 | 200 | 0~4 | Weld Joints Φ10×1 |
DMF-1-3-A | 3/8" | 10 | 18.3 | 500 | 0~4 | Flange 10 |
DMF-1-3-B | 1/2" | 15 | 36.7 | 1000 | 0~4 | Flange 15 |
DMF-1-4 | 3/4" | 20 | 110 | 3000 | 0~4 | Flange 20 |
DMF-1-5-A | 1" | 25 | 370 | 10,000 | 0~1.6 | Flange 25 |
DMF-1-5-B | 1-1/2" | 40 | 730 | 20,000 | 0~1.6 | Flange 40 |
DMF-1-6-A | 2" | 50 | 1100 | 30,000 | 0~1.6 | Flange 50 |
DMF-1-6-AB | 2-1/2" | 65 | 1800 | 50,000 | 0~1.6 | Flange 65 |
DMF-1-6-B | 3" | 80 | 3700 | 100,000 | 0~1.6 | Flange 80 |
DMF-1-6-C | 4" | 100 | 5600 | 150,000 | 0~1.6 | Flange 100 |
DMF-1-6-CD | 5" | 125 | 7400 | 200,000 | 0~1.6 | Flange 125 |
DMF-1-6-D | 6" | 150 | 11000 | 300,000 | 0~1.6 | Flange 150 |
DMF-1-6-E | 8" | 200 | 18000 | 500,000 | 0~1.6 | Flange 150 |
Other Products
Company Advantage
• Our sales terminals form a sales network throughout the domestic and international markets. It helps us to constantly set a good sales record at home and abroad.
• Sincerity has an excellent team whose team members have rich industry experience. They pay great attention to efficiency and innovation during working. They play a significant role in corporate development.
• Sincerity insists on combining standardized services with personalized services to meet customers' different needs. This contributes to the brand image building of our company's quality service.
If you have any questions, please feel free to consult Sincerity.
