What is cole parmer mass flow controller?
A Cole Parmer mass flow controller is a highly precise and reliable instrument designed to accurately measure and control the flow rate of gases in various industrial processes. This state-of-the-art device combines advanced technology with exceptional engineering, making it an indispensable tool for industries such as pharmaceuticals, chemical manufacturing, and environmental monitoring. The Cole Parmer flow meter utilizes innovative thermal measurement principles to ensure accurate readings even under dynamic conditions. Its intelligent design enables effortless integration into existing systems, allowing for efficient process automation and optimization. With its robust construction and superior performance capabilities, this controller guarantees long-term durability while maintaining consistent accuracy throughout its operational lifespan. Moreover, Cole Parmer provides comprehensive technical support services to meet any customer requirements or troubleshooting needs that may arise during installation or usage of their mass flow controllers.
Advantage of cole parmer mass flow controller
The Cole Parmer mass flow controller offers a multitude of advantages for precise and accurate control of gas or liquid flows. With its state-of-the-art design and advanced technology, this controller ensures exceptional performance in various applications. One notable advantage is its wide range of flow rates, allowing users to select the perfect level to suit their specific needs. This flexibility makes it highly versatile across industries such as pharmaceuticals, research laboratories, and manufacturing processes.
In addition, the cole parmer rotameter boasts excellent repeatability and stability thanks to its high-quality construction materials and components. This ensures consistent results over time, minimizing any variations that may interfere with experiments or production operations. Furthermore, this device incorporates advanced digital interfaces that enable easy integration into existing systems while providing real-time monitoring and control capabilities. The user-friendly interface allows for quick setup and adjustment while ensuring optimal accuracy throughout operation. Trusting in the reliability of a cole parmer rotameter guarantees efficient processes, increased productivity, enhanced experimental precision, and ultimately contributes to overall success in countless industrial settings worldwide.
Application of cole parmer mass flow controller
The Cole-Parmer mass flow controller is a highly sophisticated and versatile instrument that finds its application across various industries. With its state-of-the-art technology and precision, this device offers precise control over the flow of gases or liquids in different processes. The Cole-Parmer mass flow controller plays a crucial role in research laboratories, pharmaceutical manufacturing facilities, chemical plants, and many other settings where accurate fluid control is paramount. Its advanced features allow for easy integration into complex systems while ensuring consistent performance and reliability. Utilizing cutting-edge sensor technology combined with intelligent software algorithms, this controller guarantees exceptional accuracy even when dealing with different fluid viscosities or pressures. Moreover, it boasts user-friendly interfaces that enable operators to monitor and adjust flow rates effortlessly. Whether it's for gas chromatography analysis or fuel cell testing, the Cole-Parmer mass flow controller stands as an indispensable tool for achieving precise measurements and maintaining optimal operational conditions within diverse industrial applications.
Company Advantages
1. Several essential aspects to the inspection of Sincerity will be conducted. They are mainly the seam quality, stitch strength, needle pitch, fabric gram weight, and fabric ingredients.
2. The product has always found use in various different fields.
3. The product has stable electric performance. Its circuit boards and other electrical components are sophisticatedly soldered to guard against any external influence.
Technical Data for Sincerity TMF- Series Mass Flow Meters
0.5sccm – 6000 slm Full Scale
Standard Specifications (Contact Beijing Sincerity for available options.)
Performance | TMF -Series Mass Flow Meter |
Accuracy at calibration conditions after tare | ± 1% of Full Scale |
High Accuracy at calibration conditions after tare | ±0.5% of Full Scale High Accuracy option not available for units ranged under 5 sccm or over 3000 slm |
Repeatability | ± 0.2% Full Scale |
Zero Shift and Span Shift | 0.2% Full Scale / ºCelsius / Atm |
Operating Range / Turndown Ratio | 1% to 100% Full Scale /100:1 (200:1 optional) |
Maximum Measurable Flow Rate | 100% Full Scale |
Typical Response Time | <500 ms |
Leakage Rate | 1×10-9 atm ·cc/s He |
Operating Conditions | TMF -Series Mass Flow Meter |
Mass Reference Conditions (STP) | 25ºC & 14.696 psia (standard — others available on request) |
Operating Temperature | 0 to +50 ºCelsius |
Humidity Range (Non–Condensing) | 0 to 90% |
Maximum Internal Pressure (Static) | 145 psi(g)/10bar(g) optional: Max.1450psi(g)/100bar(g) |
Pressure Differential (Inlet to Outlet) | 145 psi(d)/10bar(d) |
Proof Pressure | 1450psi(g)/100bar(g) |
Mounting Attitude Sensitivity | None |
Ingress Protection | IP40 |
Wetted Materials |
316L 417J1 Stainless Steel, Viton, Heat Cured Silicone Rubber, Glass Reinforced Polyphen ylene Sulfide, Heat Cured Epoxy, Aluminum, Gold, Steel, Silicon, Glass. If your application demands a different material, please contact Grylls. |
Communications / Power | TMF -Series Mass Flow Meter | |
Monochrome LCD or color TFT display Integrated multifunction button | Display Mass Flow, Cumulative Flow, conversion gas coefficient and other functions | |
Digital Communications Options1 | RS-232 Serial / RS-485 Serial / Modbus RTU / PROFIBUS / EtherNet/IP / DeviceNet / Modbus TCP/IP / EtherCAT / PROFIBUS-DP | |
Analog Signal2 Options | 0-5 Vdc / 1-5 Vdc / 0-10 Vdc / 4-20 mA | |
Optional Secondary Output Signal2 | 0-5 Vdc / 1-5 Vdc / 0-10 Vdc / 4-20 mA | |
Electrical Connection Options | 9-pin D-sub (DB9) / 15-pin D-sub (DB15) / RJ11 | |
Supply Voltage | 24 Vdc / ±15Vdc | |
Supply Current | under 500slm : 0.50 Amp ; above | 500slm：1 .0Amp |
1. The Digital Output Signal communicates Mass Flow, Cumulative Flow. 2. The Analog Output Signal and Optional Secondary Analog Output Signal communicate your choice of Mass Flow, Cumulative Flow. | ||
Features | TMF -Series Mass Flow Meter |
Gas conversion coefficient V2.0 | Gas conversion coefficient provides 60 Preloaded Gas Calibrations: See the following page for a complete list. If your application calls for a gas not on this list, please let us know. We can also calibrate to a wide variety of complex gas mixtures. |
Range Specific Specifications
Full Scale Flow Mass Meter 1 | Mechanical Dimensions 2 | Process Connections3 |
TMF-series 0.5-10 sccm | ||
TMF-series 10-100 sccm | TMF- Standard series and Digital series 4.72”H x 3.15”W x 1.22”D |
G1/4” Female Thread |
TMF-series 100-500 scmm | ||
TMF-series 500-1000 sccm | ||
TMF-series 1000-2000 sccm | GM-Intelligent series | |
TMF-series 2-5 slm | ||
4.92”H x 2.76”W x 1.14”D | G3/8” Female Thread | |
TMF-series 5-20 slm | ||
TMF-series 20-30 slm | ||
TMF-series 30-100 slm |
5.12”H x 3.74”W x 1.38”D |
G3/8” Female Thread |
TMF-series 100-200 slm | ||
TMF-series 200-300 slm | ||
TMF-series 300-500 slm |
6.30”H x 6.89”W x 2.91”D |
G1/2” Female Thread |
TMF-series 500-1000 slm | ||
TMF-series 1000-2000 slm | ||
TMF-series 2000-3000 slm | ||
TMF-series 3000-6000 slm | 6.30”H x 6.89”W x 2.91”Dx2 | Double G1/2” Female Thread |
1. Lower Pressure Drops Available mass flow meters please contact Sincerity. 2. See drawings for metric equvalents. 3. Compatible with tube, face seal, push connect and compression adapter fittings. VCR and SAE connections upon request. | ||
TMF-Standard series and Digital series
0.5sccm-30slm
TMF-Intelligent series
0.5sccm-30slm
TMF-Standard series and Digital series 30slm-300slm
TMF-Intelligent series 30slm-300slm
TMF-Digital series
300slm-3000slm
TMF-Intelligent series
300slm-3000slm
Appendix: Sincerity Gas conversion coefficient V2.0
*For more single gas coefficients or mixed gas coefficients, please provide the specific heat and density of the gas medium and contact Beijing Sincerity for calculation.
